Range of Garage or Roller Door Openers and Motors
Designed especially for tight spots, this garage roller door operator only requires 90mm of side room for installation. Despite being compact in size it is packed full of features as well as being super quiet.
- 24V DC motor type
- 25m² maximum garage door size (18m² for locked doors)
- Maximum door hight: 5.5m
- 433.92 MHz transmitter frequency
- Maximum driving force: 1200N
- Minimum side room of 90mm STD / 115mm WINDCLIP (edge of curtain to wall)
- “Automatic Close Function” (when the “Photo Eye” system is fitted)
- “Overload Adjustment” included
- Optional “Photo Eye” protection
- Courtesy LED light included
- Manual disengagement system
- Electronic limit system
- Electrical input: 240V, 50Hz
- 5 year motor warranty, 2 year electronics warranty
Designed especially for tight spots, this garage roller door operator only requires 90mm of side room for installation. Despite being compact in size it is packed full of features as well as being super quiet.
- 24V DC motor type
- 8m² maximum garage door size
- Maximum door hight: 5.5m
- 433.92 MHz transmitter frequency
- Maximum driving force: 800N
- Minimum side room of 45mm (edge of curtain to wall)
- “Automatic Close Function” (when the “Photo Eye” system is fitted)
- “Overload Adjustment” included
- Optional “Photo Eye” protection
- Courtesy LED light included
- Manual disengagement system
- Electronic limit system
- Electrical input: 240V, 50Hz
- 5 year motor warranty, 2 year electronics warranty
All Marantec operators are engineered and manufactured to the highest standard to deliver optimum performance, and include quality features as standard to ensure reliable, safe and quiet operating performance year after year.
- Heavy duty motor (1,300N) designed for cyclone regions.
- Powerful DC motor which means reduced noise and vibration on opening and closing.
- 24V DC motor
- Electrical Input: 240V, 50Hz
- Rated Door area up to 22m²
- Remote distance: Effective operating range of up to 50m. +4.29 million transmitter code combinations.
- Minimum side room of 90mm (edge of curtain to wall), 45mm (edge curtain to edge bracket)
- Max peak pulling force: 1000N
- 433.92MHz transmitter frequency with multi-bit technology
- LED courtesy light
- Soft start/stop function
- Manual disengagement system
- Electronic limit system
- 5 year motor warranty, 2 year electronics warranty.
- Heavy duty motor (1,300N) designed for cyclone regions.
- RCM Accredited (Regulatory Compliance Mark) & European STD DIN/EN 13241-1.
- Powerful DC motor which means reduced noise and vibration on opening and closing.
- 24V DC motor
- Electrical Input: 240V, 50Hz
- Rated Door area up to 25m²; 18m² for wind locked doors
- Remote distance: Effective operating range of up to 50m. +4.29 million transmitter code combinations.
- Minimum side room of 90mm (edge of curtain to wall), 45mm (edge curtain to edge bracket)
- Max peak pulling force: 1300N
- 433.92MHz transmitter frequency with multi-bit technology
- LED courtesy light
- Soft start/stop function
- Manual disengagement system
- Electronic limit system
- 2 year motor warranty, 2 year electronics warranty.
